ABL Circuits PCB Manufacturing Routing

ABL Circuits PCB Manufacture Routing

ABL Circuits PCB Manufacture Routing

The final process in the board manufacture is to rout out the boards to size on a CNC Routing Machine which can be programmed from the original CAD data or manually with a video camera and joystick. The boards can either be left in a panel or routed out as singles, lots of companies prefer left in a panel because it aids assembly especially if the boards are quite small. The precision dimensions can be achieved because the stepper motors on the machines go down to 100th of a millimetre so accuracy is ensured and the other process at the final stage of the panel process is scoring.
