ABL Circuits PCB Manufacture Drilling The Holes

ABL Circuits PCB Manufacture Drilling The Holes

ABL Circuits PCB Manufacture Drilling The Holes

The next process in PCB Manufacture – drilling the holes on the panels on the CNC Drilling machine on which we can drill right down to 0.3mm diameter which will give a finished hole of 0.2mm and we go up to 6.5mm diameter. The panels are loaded in either manually or they can be auto loaded and run unaided through the night. It auto loads and auto unloads, the machine runs unmanned if necessary. It laser detects the drill diameter so that it cannot drill the wrong size hole and also checks for concentricity of the drill so that it is running true, and it adjusts the feeds and speeds to suit the drill size.
